Order No.: 110793
Model: MGB-L1-ARA-AA2A1-S1-L
Locking type: Guard locking by spring force, release by solenoid
Door hinge: DIN left
Emergency stop: 2 positively driven contacts, turn-to-reset
Pushbuttons: 1x yellow, illuminated, 1 NO contact / 1x white, illuminated, 1 NO contact
Protection rating: IP65
Operating temperature: -20 ... +55 °C
Connection: Plug connector RC18
Power supply: 24 V DC (-15% / +10%)
Current consumption: max. 375 mA (UA), max. 80 mA (UB)
Safety outputs: 2x FO1A/FO1B, p-switching, short-circuit proof
Coding: Unicode
Status indication: LED
Label carrier: incl. adhesive labels
Standards: PL e, SIL 3, EN ISO 13849-1, EN IEC 62061
Mechanical life: 1 million operations
Locking force: 2000 N
GTIN: 4047048005969
Weight: 1.063 kg
