TVP 2.51-50-W0
Free shipping from 49€
Worldwide shipping
- Manufacturer: Indramat
- Model: TVP 2.51-50-W0
- Device class: power supply module
- System: AC drive system (TDM / TDA / KDA / KDS)
- Mains input: 3 × 220 V AC (+15 / −10%), 50–60 Hz
- Rated current: 50 A
- Peak current: approx. 150 A
- DC link voltage: 300 V DC (±15%)
- Rated power: approx. 15 kW
- Bleeder power: 300 W continuous / 10 kW peak
- Regenerative energy: max. approx. 14 kWs
- Power loss: max. approx. 400 W
- Control voltages: +24 V (4 A), ±15 V (each 0.85 A)
- Cooling: natural convection (no fan)
- Ambient temperature: +5 to +45 °C
- Installation altitude: ≤ 1000 m
- Protection rating: IP10
- Insulation class: C
- Humidity class: F
- Dimensions: 260 × 320 × 210 mm
- Weight: approx. 9 kg
